H101-15 Miniature Compression Force Sensor

The H101-15 Miniature Compression Force Sensor is designed for compression force measurement with model-specific verified load-cell specifications. Contact Bonida CNC for configuration and quotation. Technical Specifications Capacity: 1, 2, 5, 10 t Rated output: 2.0 ±0.05 mV/V Zero balance: ±1% F.S. Creep: ±0.1% F.S. Non-linearity: ±0.1% F.S. Hysteresis: ±0.1% F.S. Repeatability: ±0.1% F.S. Input impedance: 750 ±50 Ω Output impedance: 700 ±5 Ω Temperature effect on sensitivity: ±0.1% F.S./10°C Temperature effect on zero: ±0.1% F.S./10°C Insulation resistance: ≥5000 MΩ/50 VDC Recommended excitation: 5-10 VDC Maximum excitation: 15 VDC Compensated temperature range: -10 to 40°C Operating temperature range: -20 to 60°C Safe overload: 150% F.S. Ultimate overload: 200% F.S. Cable: Ø5.3 × 3 m Protection: IP66 Accuracy class: 0.1% F.S.
